HINO 700 Series Profia
SPESIFIKASI UNIT
SS SERIES 6×4
SS1E TH
| Mechanical | ||
| Performa | ||
| Maximum Speed (KM/H) | 119(KM/H) | |
| Grade Ability (tan Ø) | 51.3 | |
| Engine Model | ||
| Model | e13c vt | |
| Model Type | diesel 4 stroke, in line common rail | |
| Maximum Power (PS/rpm) | 480 / 1800 | |
| Maximum Torque (Kgm/rpm) | 220 / 1100 | |
| Nos of Cylinder | 6 | |
| Bore X Stroke (mm) | 137 x 146 | |
| Piston Displacement (cc) | 12 ,913 | |
| Clutch | ||
| Clutch Type | dry twin plate with damper spring | |
| Diameter Cakram | 387 | |
| Transmission | ||
| Transmission Type | eaton rtl016918b 18 speed | |
| Gear Ratio | 4.555 | |
| C | – | |
| 1st | 14,402 / 12,287 | |
| 2nd | 8,561 / 7 ,303 | |
| 3rd | 6,048 , 5,160 | |
| 4th | 4.384 / 3.740 | |
| 5th | 3.201 / 2.731 | |
| 6th | 2 288 1 ,952 | |
| 7th | 1,617 / 1 ,379 | |
| 8th | 1.172 / 1 .000 | |
| Reverse | low 15.057 / 12.485 | |
| Steering | ||
| Steering Type | integral power steering recirculating with hydrolic booster | |
| Min. Turning Circle | 7.5 m | |
| Axle | ||
| Rear | full floating type hypoid gear | |
| Front | reversed elliot i section | |
| Final Gear Ratio | 4 ,555 | |
| Drive System | 6 x 4 | |
| Brakes | ||
| Main Brake | full air brake with dual circuit include abs | |
| Exhaust Brake | engine retarder | |
| Parking Brake | wheel parking | |
| Wheel & Tire | ||
| Wheel Disc Size | 22, 5 x 7 50v 165 | |
| Tire Size | 11r-22,5 | |
| Nos of Tire | 10 (+1) | |
| Suspensions | ||
| Front & Rear | semi elliptical leaf spring with shock absorber stabilizer semi elliptical leaf spring with shock absorber torque rod | |
| Electric Battery | ||
| Battery | 12v 120ah x 2 | |
SV SERIES 6×4
SV Series (6x4)
| Mechanical | ||
| Performa | ||
| Maximum Speed (KM/H) | 81 (KM/H) | |
| Grade Ability (tan Ø) | 120 | |
| Engine Model | ||
| Model | e13c tt | |
| Model Type | Diesel 4 Stroke, In Line (Common Rail) | |
| Maximum Power (PS/rpm) | 450 / 1800 | |
| Maximum Torque (Kgm/rpm) | 220 / 1100 | |
| Nos of Cylinder | 6 | |
| Bore X Stroke (mm) | 137 x 146 | |
| Piston Displacement (cc) | 12 ,913 | |
| Clutch | ||
| Clutch Type | single dry plate with damper spring | |
| Diameter Cakram | 430 | |
| Transmission | ||
| Transmission Type | zf 16as2630 to | |
| Gear Ratio | – | |
| C | – | |
| 1st | 14,120 / 11,677 | |
| 2nd | 9,539 / 7,889 | |
| 3rd | 6,521 / 5,393 | |
| 4th | 4.565 / 3.776 | |
| 5th | 3.093 / 2.558 | |
| 6th | 2 089 1 ,728 | |
| 7th | 1,428 / 1 ,181 | |
| 8th | 1.000 | |
| Reverse | 13.074 / 10.812 | |
| Steering | ||
| Steering Type | intergral power steering recirculating with hydrolic booster | |
| Min. Turning Circle | 10 | |
| Axle | ||
| Rear | reversed elliot i section | |
| Front | full floating type spiral bevel gear with hub reduction | |
| Final Gear Ratio | 7, 21 | |
| Drive System | 6 x 4 | |
| Brakes | ||
| Main Brake | full air brake with dual circuit include abs | |
| Exhaust Brake | engine retarder | |
| Parking Brake | wheel parking | |
| Wheel & Tire | ||
| Wheel Disc Size | 24 x 8.50-180 | |
| Tire Size | 12.00-r24-18pr | |
| Nos of Tire | 10 (+1) | |
| Suspensions | ||
| Front & Rear | semi elliptical multi leaf spring with shock absorber semi elliptical multi leaf spring with torque rods | |
| Electric Battery | ||
| Battery | 12v 120ah x 2 | |
ZS Series 6×4
ZS4141
| Mechanical | ||
| Performa | ||
| Maximum Speed (KM/H) | 75 (KM/H) | |
| Grade Ability (tan Ø) | 60 | |
| Engine Model | ||
| Model | e13c wd 2 | |
| Model Type | diesel 4 stroke, in line common rail | |
| Maximum Power (PS/rpm) | 410 / 1800 | |
| Maximum Torque (Kgm/rpm) | 204 / 1100 | |
| Nos of Cylinder | 6 | |
| Bore X Stroke (mm) | 137 x 146 | |
| Piston Displacement (cc) | 12 ,913 | |
| Clutch | ||
| Clutch Type | single dry plate with damper spring | |
| Diameter Cakram | 430 mm | |
| Transmission | ||
| Transmission Type | zf 16s2530 | |
| Gear Ratio | – | |
| C | – | |
| 1st | 13.804/11.539 | |
| 2nd | 9,487 / 7,930 | |
| 3rd | 6,529 / 5,458 | |
| 4th | 4.565/ 3.816 | |
| 5th | 3.023 / 2.527 | |
| 6th | 2978 1,737 | |
| 7th | 1,430 / 1,195 | |
| 8th | 1000 / 835 | |
| Reverse | 12923 / 10,803 | |
| Steering | ||
| Steering Type | telescopic and tilt steering column with locking devicerecirculating ball with hydraulic booster integral type | |
| Min. Turning Circle | 11 2 m | |
| Axle | ||
| Rear | tandem axle dual drive with inter axle differential and manual cross differential lock full floating hub reduction | |
| Front | msf 20 series reversed elliot i section | |
| Final Gear Ratio | ,721 | |
| Drive System | 6 x 4 | |
| Brakes | ||
| Main Brake | 785 | |
| Exhaust Brake | 786 | |
| Parking Brake | 787 | |
| Wheel & Tire | ||
| Wheel Disc Size | 24 x 8,50-180 | |
| Tire Size | 00-r24,12 | |
| Nos of Tire | 10 (+1) | |
| Suspensions | ||
| Front & Rear | semi elliptical tapperd leaf spring with shock absorber stabilizer semi elliptical multi leaf spring with stabilizer torque rod | |
| Electric Battery | ||
| Battery | 12v 120ah x 2 | |
ZS4141 (AMT)
| Mechanical | ||
| Performa | ||
| Maximum Speed (KM/H) |
75(KM/H) |
|
| Grade Ability (tan Ø) |
60 |
|
| Engine Model | ||
| Model |
e13c wd 2 |
|
| Model Type |
mesin diesel 4 langkah segaris direct injection turbo charge intercooler |
|
| Maximum Power (PS/rpm) |
410 / 1800 |
|
| Maximum Torque (Kgm/rpm) |
204 / 1100 |
|
| Nos of Cylinder |
6 |
|
| Bore X Stroke (mm) |
137 x 146 |
|
| Piston Displacement (cc) |
12 ,913 |
|
| Clutch | ||
| Clutch Type |
dry single plate with damper spring automatic gap adjuster |
|
| Diameter Cakram |
430 mm |
|
| Transmission | ||
| Transmission Type |
amt 16 speed, zf 16as2630to |
|
| Gear Ratio |
– |
|
| C |
– |
|
| 1st |
13,804 / 115,392 |
|
| 2nd |
9,487 , 79,302 |
|
| 3rd |
6.529 / 54.582 |
|
| 4th |
4.565 /38.162 |
|
| 5th |
3.023 / 25.272 |
|
| 6th |
2078 1,737 |
|
| 7th |
1,430 / 119,5 2 |
|
| 8th |
1, 000 |
|
| Reverse |
1.2923 / 10.803 |
|
| Steering | ||
| Steering Type |
intergral power steering recirculating with hydrolic booster |
|
| Min. Turning Circle |
111 m |
|
| Axle | ||
| Rear |
tandem axle dual drive with inter axle differential and manual cross differential lock full floating hub reduction |
|
| Front |
reverse elliot i section beam |
|
| Final Gear Ratio |
7,210 |
|
| Drive System |
rear 6 x 4 |
|
| Brakes | ||
| Main Brake |
full air with dual circuit include abs |
|
| Exhaust Brake |
engine retarder |
|
| Parking Brake |
f1, r1 r2, wheel parking |
|
| Wheel & Tire | ||
| Wheel Disc Size |
24 x 8.50-180 |
|
| Tire Size |
00-r24-18pr, 12 |
|
| Nos of Tire |
10 (+1) |
|
| Suspensions | ||
| Front & Rear |
semi elliptical multi leaf spring with shock absorber stabilizer |
|
| Electric Battery | ||
| Battery |
12v 120ah x 2 2 |
|
ZY Series 8×4
ZY1EWPD
| Mechanical | ||
| Performa | ||
| Maximum Speed (KM/H) | 99 (KM/H) | |
| Grade Ability (tan Ø) | 52.7 | |
| Engine Model | ||
| Model | e13c wd | |
| Model Type | diesel 4 stroke | |
| Maximum Power (PS/rpm) | 410 / 1800 | |
| Maximum Torque (Kgm/rpm) | 204 / 1100 | |
| Nos of Cylinder | 6 | |
| Bore X Stroke (mm) | 137 x 146 | |
| Piston Displacement (cc) | 12 ,913 | |
| Clutch | ||
| Clutch Type | single dry plate with damper spring | |
| Diameter Cakram | 430 mm | |
| Transmission | ||
| Transmission Type | zf 16s2530 | |
| Gear Ratio | – | |
| C | – | |
| 1st | 13.804/11.539 | |
| 2nd | 9,487 / 7,930 | |
| 3rd | 6,529 / 5,458 | |
| 4th | 4.565/ 3.816 | |
| 5th | 3.023 / 2.527 | |
| 6th | 2978 1,737 | |
| 7th | 1,430 / 1,195 | |
| 8th | 1000 / 835 | |
| Reverse | 12923 / 10,803 | |
| Steering | ||
| Steering Type | telescopic and tilt steering column with locking devicerecirculating ball with hydraulic booster integral type | |
| Min. Turning Circle | 13 500 | |
| Axle | ||
| Rear | tandem axle dual drive with inter axle differential and manual cross differential lock full floating hub reduction | |
| Front | msf 20 series reversed elliot i section | |
| Final Gear Ratio | 5, 41 | |
| Drive System | 8 x 4 | |
| Brakes | ||
| Main Brake | 785 | |
| Exhaust Brake | 786 | |
| Parking Brake | 787 | |
| Wheel & Tire | ||
| Wheel Disc Size | 24 x 8.50-180 | |
| Tire Size | 12 00 r24 | |
| Nos of Tire | 12 (+1) | |
| Suspensions | ||
| Front & Rear | semi elliptical multi leaf spring with shock absorber stabilizer semi elliptical multi leaf spring with stabilizer torque rod | |
| Electric Battery | ||
| Battery | 12v 120ah x 2 | |
